Silicon carbide TUF membrane

Product Description
Detailed Images

Silicon carbide TUF membrane


Effective filtration area5 ㎡
Average aperture100/400nm
PH1-14
Operating temperature5-45 ℃
Length1828.8mm
Sealing methodO-ring
Maximum working pressure-700mbar
Maximum backwash pressure3bar
Flux50-1000L/㎡ · hr
Cleaning methodphysical cleaning/chemical cleaning


Characteristics of silicon carbide TUF membrane


1. It is made of high-purity silicon carbide powder and sintered at high temperature. It is currently the best membrane material with the best hydrophilicity and anti-pollution ability.

2. The highly negatively charged membrane surface ensures excellent pollution resistance on the membrane surface within a wide pH range;

3. Ideal operating conditions - when the added amount of PAC makes the pH less than 6. The membrane surface can maintain a negative charge of -25~-30 millivolts, making it difficult for dissolved organic carbon and transparent outer polymer particles to adhere to the membrane surface;

4. It is easy to clean negatively charged substances in the water body from the membrane surface, such as bacteria, algae, MLSS, transparent outer polymer particles and oil substances.
